Wharfedale WLA-25

System Continuous Power 160w
System Programme Power 320w
System Peak Power 640w
Crossover frequency 3.7kHz

Frequency Response (+/-3dB) 108Hz - 18kHz
Frequency Range (-10dB) 108Hz - 20kHz
Sensitivity (2.83v/1m) HF:108dB/LF:100dB
Calculated Maximum SPL @1m HF:135dB/LF:127dB
System Rated Impedance 16Ohm
LF Transducer
Size 130mm / 5'
Voice-Coil Size 35mm / 1.4'
Rated Impedance 16Ohm
LF Power (re:AES2-2012) 2 60w
HF Transducer
HF Driver Type Compression Driver
Voice-Coil Size 44mm / 1.75'
Exit size 1'
Diaphragm Material Titanium
Rated Impedance 16Ohm
HF Power (re:AES2-2012) 40w
Nominal Coverage (H x V) 100 x 10
Power
System Continuous Power 160w
System Programme Power 320w
System Peak Power 640w
Crossover frequency 3.7kHz
Hardware
Input Connector 2 x speakON compatible
Integral side plate adjustable rigging 0-10
Enclosure
Enclosure Material 15mm,18mm Plywood
Finish Rhino Black or white paint
Grille Material Steel
Dimensions - unpacked
Height 164.5mm / 6.47'
Width 536mm / 21.10'
Depth 363mm / 14.29'
Dimensions - packed
Height 235mm / 9.25'
Width 606mm / 23.85'
Depth 430mm / 16.92'
Weight
Net Weight 13kg / 28.66lbs
Gross Weight 15kg / 33.06lbs
